Modell | A10e | A20e | A30e | A41e | A80e | A100e | A110e | A150e | A200e | A250e |
---|---|---|---|---|---|---|---|---|---|---|
Wellenleistung | 1.000W | 2.000W | 3.000W | 4.100W | 8.000W | 10.000W | 11.000W | 15.000W | 20.000W | 25.000W |
Eingangsleistung | 1.090W | 2.180W | 3.260W | 4.450W | 8.690W | 10.870W | 11.950W | 16.300W | 21.690W | 27.080W |
Wirkungsgrad | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 |
Spannung | 24V | 24V | 36V | 48V | 48V | 72V | 48V | 48V | 96V | 96V |
Stromaufnahme | 45A | 87A | 89A | 93A | 178A | 151A | 249A | 339A | 225A | 281A |
Gewicht | 19kg | 27kg | 28kg | 29kg | 42kg | 44kg | 55kg | 56kg | 58kg | 59kg |
Motortyp | Sensorloser AC-Drehstrommotor | |||||||||
Aufhängung | Mit Sterngriffschrauben oder wahlweise mit Fixverschraubung | |||||||||
Trimmvorrichtung | Manuell 4-stufig einstellbar | |||||||||
Garantie | 2 Jahre | |||||||||
Modell | UF10e | UF20e | UF30e | UF41e | UF80e | UF100e | UF110e | UF150e | UF200e | UF250e |
---|---|---|---|---|---|---|---|---|---|---|
Wellenleistung | 1.000W | 2.000W | 3.000W | 4.100W | 8.000W | 10.000W | 11.000W | 15.000W | 20.000W | 25.000W |
Eingangsleistung | 1.090W | 2.180W | 3.260W | 4.450W | 8.690W | 10.870W | 11.950W | 16.300W | 21.690W | 27.080W |
Wirkungsgrad | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 |
Spannung | 24V | 24V | 36V | 48V | 48V | 72V | 48V | 48V | 96V | 96V |
Stromaufnahme | 45A | 87A | 89A | 93A | 178A | 151A | 249A | 339A | 225A | 281A |
Gewicht | 19kg | 25kg | 26kg | 27kg | 40kg | 42kg | 53kg | 54kg | 56kg | 57kg |
Motortyp | Sensorloser AC-Drehstrommotor | |||||||||
Aufhängung | Serienmäßig Hennegatsrohr, optional mit vibrations- und schallgedämpften Lenkturm | |||||||||
Garantie | 2 Jahre | |||||||||
Modell | F10e | F20e | F30e | F41e | F80e | F100e | F110e | F150e | F200e | F250e |
---|---|---|---|---|---|---|---|---|---|---|
Wellenleistung | 1.000W | 2.000W | 3.000W | 4.100W | 8.000W | 10.000W | 11.000W | 15.000W | 20.000W | 25.000W |
Eingangsleistung | 1.090W | 2.180W | 3.260W | 4.450W | 8.690W | 10.870W | 11.950W | 16.300W | 21.690W | 27.080W |
Wirkungsgrad | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 |
Spannung | 24V | 24V | 36V | 48V | 48V | 72V | 48V | 48V | 96V | 96V |
Stromaufnahme | 45A | 87A | 89A | 93A | 178A | 151A | 249A | 339A | 225A | 281A |
Gewicht | 12kg | 19kg | 20kg | 21kg | 33kg | 35kg | 46kg | 47kg | 49kg | 50kg |
Motortyp | Sensorloser AC-Drehstrommotor | |||||||||
Ausgleichskeil | Ja-serienmäßig maßgefertigt | |||||||||
Garantie | 2 Jahre | |||||||||
Typ | MA25 | MA35 | MA43 | MA70 | MA110 | MA160 | MA300 | |
---|---|---|---|---|---|---|---|---|
Wellenleistung | 2.500W | 3.500W | 4.300W | 7.000W | 11.000W | 16.000W | 30.000W | |
Eingangsleistung | 2.800W | 3.960W | 4.830W | 7.860W | 12.350W | 17.970W | 32.600W | |
Wirkungsgrad | 0.89 | 0.89 | 0.89 | 0.89 | 0.89 | 0.89 | 0.89 | |
Spannung | 24VDC | 36VDC | 48VDC | 48VDC | 48VDC | 72VDC | 96VDC | |
Stromaufnahme | 104A | 108A | 99A | 161A | 240A | 239A | 330A | |
Motortyp | sensorloser AC-Drehstommotor | |||||||
Aufhängung | 3-D versellbare Aufhängung | |||||||
Garantie | 2 Jahre | |||||||
